Frequency modulated, continuous wave radar for solids and liquids

April 28, 2023

W-200 Pilotrek is a compact, 80 GHz, frequency modulated, continuous wave (FMCW) radar transmitter for solids and liquids. Its new WES series model is a two-wire, 24 VDC, loop-powered radar transmitter, which uses the highly accurate FMCW technique. WES operates as low as 12 volts DC, and provides ±0.078-inch accuracy, 0.039-inch resolution. It also has up to 98 feet range, 7° beam angle, and measures dielectrics as low as 1.9.

Nivelco USA LLC
