Otto Bock plant uses Profinet, smart drives for accurate liquid plastic mixing

Feb. 27, 2019
Upgrade improves accuracy and quality, and drives savings

Until the 1950s, the Otto Bock company focused on fabricating prostheses, which were still made of wood. However, even as supplies of appropriate wood became scarce, the firm was already considering more suitable materials, which turned out to be synthetics such as plastics.

Founded by Mr. Otto Bock in Germany in 1919, following World War I, the company has marketed polyurethane foam products and systems for more than 60 years. Otto Bock Kunststoff GmbH is headquartered in Duderstadt, while its North American headquarters were established in 1958 in Minneapolis, Minn. More recently, it was wholly acquired by FoamPartner/Conzzeta AG based in Wolfhausen, Switzerland.

Otto Bock reports its 5,000 employees focus on efficient, high-quality manufacturing at all its facilities in Germany, the U.S. and China. That efficiency, whether it's on the production line or in engineering design, is the primary goal, but achieving it requires an integrated approach where every element contributes to the greater whole.

This big-picture view was the driving force for engineering recommendations made by system integrator Process Automation Solutions (PAS) for a new Otto Bock plant in Rochester Mills, Mich., near Detroit. Located in Atkinson, N.H., PAS is an associate member of the Control System Integrators Association (CSIA).

Smart drive cabinet

Figure 1: To control the accuracy and quality of its liquid polymer blending process, Otto Bock worked with system integrator PAS to design a control system built on a foundation of Profinet and 18 smart drives from Siemens. Source: PAS

Built in 2018 next to the company's production facility, workstations at the new plant blend liquid polymers for the soft, nonflammable, sound-absorbing plastic parts used inside vehicles or similar applications. The result of PAS' input was a state-of-the-art controls system built on a foundation of Profinet and 18 smart drives from Siemens (Figure 1).

"Our thought is to always save as much money for clients as possible, though that doesn't always mean the lowest initial cost," says Ingo Magura, senior project manager at PAS. "We tend to review with clients all aspects. For instance, using a reputable electrical installation contractor with a history of such projects may be a better long-term fit than a subcontractor that is less expensive at first, but has no experience with control system installations."

Polymer blending process

To begin its batch process, Otto Bock receives truck deliveries of different polymers, which are transferred by automated pumps into one of four storage tanks. Operators then start one of their 20 recipes, and add different polymers in varying quantities to one of three mixing tanks, which circulate and mix the raw materials before the operators manually add quantities of special additives. When a batch is approved by the quality assurance/control department (QA/QC), the final liquid polymer product is automatically pumped into 1,000-kg totes, smaller storage bins, or into other trucks for delivery to customers.

Tight batch process control is critical for ensuring final product quality, and requires controlling setpoints, current flow and motor speeds, as well as monitoring equipment status to detect potential faults. This process criticality helped underscore the case for using networked smart drives for Otto Bock's new control system, which would allow online diagnostics from the engineering station as well as remote accessibility.

"Exact quantities are key to this polymer blending application, including the amount pumped from a storage tank into a mixing tank, and also the quantity of finished product transferred into the totes before shipping," says Magura. "In this case, tight batch control means speed for agitation while mixing product, so exact quantities are pumped. Upgrading to automated systems from the company's former manual procedures has labor efficiencies and increases accuracy."

The smart approach

Although Otto Bock originally intended to use a traditional, motor-mounted drive system, PAS calculated that using networked smart drives would significantly reduce engineering, hardware and commissioning time and costs, as well as contribute additional information needed for measuring system performance.

"In the old facility, there was an old control system by a little-known brand with limited capabilities and pretty much no support," adds Magura. "The new system is energy-efficient, automated (reducing manual intervention), allows automatic reports, and is remote-accessible through a secure connection."

Control components in the polymer blending solution by PAS include Siemens TIA Portal v15 software, WinCC SCADA system, S7-1515 CPU and remote I/O rack, as well as 18 Siemens Sinamics G120 drives and two Siemens Comfort panel field HMIs—all networked with Profinet. The drives work with 460-V, 3-phase NEMA motors, ranging from 1.25 kw to 11 kW, which serve the blending application's pumps and agitators (Figure 2).

Engineering setup with Profinet

Figure 2: Control components in the polymer blending solution by PAS include Siemens TIA Portal v15 software, WinCC SCADA system, S7-1515 CPU and remote I/O rack, as well as 18 Siemens Sinamics G120 drives and two Siemens Comfort panel field HMIs—all networked with ProfiNet. The drives work with 460 V, 3 ph NEMA motors, ranging from 1.25 kw to 1 kW, which serve the blending application's pumps and agitators. Source: PAS

"Having the smart drives, Profinet and the control system allows for seamless integration," says Magura, who was confident that this integrated approach would achieve the goals set for the new blending facility, and details how using smart drives networked by Profinet reduced Otto Bock's hardware and commissioning expenses.

"Since Profinet already connects all the components, commissioning time is drastically reduced compared to using traditional drives, which require that a dedicated cable be hooked up to each drive from an engineering laptop PC for commissioning," he explains. "In contrast, with smart drives connected by Profinet to the PLC, there's just one Ethernet cable, compared to eight that would have been needed if Ethernet wasn't used."

The functions of these cables include:

  • Speed setpoint (4-20 mA);
  • Actual speed (4-20 mA);
  • Actual current (4-20 mA);
  • Drive Ready (discrete input);
  • Drive Enable (discrete output);
  • Drive Fault (discrete input);
  • Drive START (discrete output); and
  • Drive STOP (discrete output).

"Since no additional hardware such as I/O cards is required to read the actual speed of the drive/motor, this technology enhances accuracy. Plus, when you multiply these cabling and I/O costs by 18 drives, it becomes evident that a smart bus system reduces both hardware and cable installation costs. The cabling and I/O would have cost at least $31,000 more if hadn't wired the drives to the PLC using Profinet.

"In addition, remote access to PAS has been implemented with Siemens Sinema Remote Connect system, which is secure and allows us to perform software modifications or troubleshoot remotely. Production adjustments can be from a password-protected screen on the WinCC SCADA system."

Multiple ongoing gains

Beyond initial equipment and commissioning savings, deploying smart drives and Profinet is paying ongoing dividends for both Otto Bock and PAS, according to Magura. "Profinet is deterministic, so we can fine tune the control loops immediately and efficiently," he said. "In addition, we have all the measured values from the devices at our disposal, such as hours run, which can be sent from a drive to the PLC in a few mouse clicks. That's efficient engineering.

"By using this fully integrated control system platform, including the drives, HMIs and Profinet, we were able to estimate our engineering costs more tightly, reduce the price to the customer, and demonstrate that PAS is a more efficient solution partner."

Finally, key performance indicators (KPI) can be easily calculated using the vast amount of data now available from the company's polymer blending application. This Profinet networked system also makes it easy for users to add new KPIs by analyzing data from the smart drives. These KPIs also bring further insights into Otto Bock's network and manufacturing process, and are potentially critical for planning preventive maintenance and future hardware upgrades.

"As for the future, Otto Bock has similar blending systems in Germany and Asia," concludes Magura. "So, the goals of its U.S. team apply these best practices in the other facilities."
