FujiFilm fast-tracks America’s largest cell culture CDMO

Oct. 5, 2023
Jacob Grønnegaard of FujiFilm Diosynth Biotechnologies discussed how the company’s unique cloning processes dramatically reduce project execution time, effort and expense at this week’s Emerson Exchange Immerse.

More than 2 billion people worldwide do not have access to medicine, and it’s only getting worse. The COVID-19 pandemic showed that ramping up the production of medicines at breakneck speed can be of vital importance. The next time a pandemic hits the life sciences industry must be equipped and ready.

The good news is that they will be, thanks to efforts such as the one being put forth by FujiFilm Diosynth Biotechnologies, a global contract development and manufacturing organization (CDMO) and provider of cell and gene therapy and viral vaccine products. FujiFilm doesn’t make its own products, it quickly gets them to market for others. It offers solutions for cell line development, process development, late phase activities, clinical and commercial manufacturing of a wide variety of biopharmaceuticals. CDMOs can be a vital cog in a well-orchestrated effort to quickly manufacture vaccines, such as happened during the pandemic.

FujiFilm is looking ahead and building the largest cell culture CDMO in North America, located in Holly Springs, N.C. The 1 million-square-foot facility will be ready for production in 2025. The company has additional U.S. locations in Cambridge, Mass., College Station, Texas, and Thousand Oaks, Calif., in addition to Hillerød, Denmark, and Teesside, U.K.

Jacob Grønnegaard, director of automation for FujiFilm Diosynth Biotechnologies, was on hand at Emerson Exchange Immerse 2023 in Anaheim, Calif., and told a captivated audience that the company has speed and flexibility in mind as it builds its latest facility.

“We change products, so we need to have flexibility in our facilities,” he said.

Replicate to gain efficiency

FujiFilm has been through this process before. The Holly Springs site is a nearly identical clone to its Hillerød facility. “We take a different approach. We want to reduce the time to completion,” Grønnegaard said.

That’s why FujiFilm uses a cloning-across-sites system that is built on utilizing Drug Substance Manufacturing (DSM) modules. The modules are designed with identical automation concepts intended to allow for fast scalability for production and agility and redundancy for supply chain management.

Grønnegaard said the company increases cloning percentage as a project progresses. “As we move from DSM expansion to completion, we increase the percentage with the ultimate goal of delivering the completed project in less than 24 months lead time, 50% of the working hours and 85% of the installed costs of the previous facility.”

DSM modules

What is a DSM module? The modules are the core of the facility, and it’s where the production takes place. Each module consists of two upstream trains, four production bioreactors, a harvest suite and a purification suite.

Such a highly sensitive environment needs a high-level system architecture. Each DSM module has its own Emerson DeltaV automation system and two DSM modules will share an Emerson Syncade manufacturing execution system (MES).

The DSM modules in Holly Springs will be the same as in the Denmark facility. Both facilities have the same layout and process equipment. They have the same process and instrumentation diagrams (P&IDs) and 3D engineering models. Most notable is that they will have the same DeltaV and Syncade application code. The only localization, according to Grønnegaard, will be for required building code differences between the U.S. and Denmark, such as electrical standards. Both facilities will be governed by the same standard operating procedures.

Application code process

Grønnegaard outlined FujiFilm’s DeltaV application code development process utilizing its unique cloning procedure during the session. Before the process even begins, the application code is developed for the initial DSM and goes through full qualification testing.

From there, FujiFilm exports the DeltaV code and design documents. It uses a qualified tool to convert tag numbers complete with code and graphics from the initial DSM to the new DSM. It uses a qualified tool to update design documents with the new DSM tag numbers.

FujiFilm then implements any changes that exist between the new DSM and initial DSM. From there, it qualifies each change individually. Finally, the DeltaV code is qualified ready for use during equipment commissioning.

The result is intended to be one of the top medicine production facilities in the country. Hopefully, it won’t have to ramp up production for a virus vaccine to combat a worldwide pandemic, but if the time ever comes again, it will be scalable and ready.
